technical parameters

product model：sat-c9732p3838nl078yz65

sensor：aptina

scanning frequency h：pal:15.625 khz/ ntsc: 15.734 khz

scanning frequency v：pal: 50hz / ntsc: 59.94 hz

image sensor：ov9732 plcc28

total pixels no.：1280(h)x720(v)

effective pixels no：pal)/ ntsc: 1280(h)x720(v)

horizontal resolution：hd

luminance s/n：46db

min. illumination：0.1lux@（f1.2 agc on）

video output signal：1vp-p composite(75ohm)

lens：manual

input power：dc12v 500ma

current：max 50±10ma

maximun power consumption：max 0.6w

dimensions：38mmx38mmx24(t)mm

environment humidity：operating（工作）：from10% to 85% relative humidity (non-condensing).

store（储存）：from 0% to 95% relative humidity (non-condensing).

altitude：operating（工作）：to10, 000ft

store（储存）：to20, 000ft

working temperature：-20℃—60℃

storage temperature：-20℃—80℃
