4.3,tft lcd moudle |
sat-581-bz043d-ak-n |
|
technical parameters |
||
|
tft brand |
tm/chimei |
|
|
screen size |
diagonal 4.3 inch |
|
|
resolution |
320（r.g.b）×240 |
|
|
valid display area |
70.08（h）×52.56（v）mm |
|
|
color style |
r.g.b beeline array |
|
|
aspect ratio |
4:3 |
|
|
brightness |
350cd/㎡(typ.) |
|
|
working voltage |
dc9-18v （standard: dc12v） |
|
|
working current(dc12v) |
dc160ma±30ma |
|
|
signal system |
pal/ntsc automatic identify |
|
|
video signal input |
0.5-2 vp-p/75ω(standard value:1.0 vp-p) |
|
|
|
(0.714vp-p video signal,0.286vp-p sync signal) |
|
|
startup time |
≤1.8s |
|
|
power consumption |
<2.2w |
|
|
working temperature |
-20℃-60℃ |
|
|
storage temperature |
-30℃-70℃ |
|
|
relative humidity |
10%～80%（rh） |
|
